Leaders in bond test technology of the world:

Key Features:

• Wire Pull full ranges can be selected from: 0-100g; 0-1kg; 0-10Kg;

• Ball Shear ranges can be selected from: 0-250g, Solder Ball Shear:0- 5Kg;

• Die Shear ranges can be selected from: 0-100Kg or 0-200Kg.

• Tweezer Pull/Peel ranges can be selected from to 5Kg;Cold Bump Pull: 5kg

• Options function: Hot Bump pull; Vectored Pull; Auto-testing….

Specifications:

Machine Footprint： D: 730mm W:425mm H: 670mm

Weight:45kg

Power Supply： Switchable 100/110v，220/240V AC 50/60 Hz

International Certification： MIL STD 883; JEDEC; JEITA; European CE Regulations; Safety Directive…
